Here are the detailed specifications for a refurbished Kobelco SK210LC excavator:

Operating Weight and Dimensions

• Operating Weight: 21,000–21,800 kg
• Overall Length: ~9.7–9.9 meters
• Overall Width: ~2.99–3.0 meters
• Overall Height: ~3.0–3.1 meters
• Tail Swing Radius: ~2.75 meters
• Ground Clearance: ~470 mm
• Track Width: 600 mm standard

Engine and Powertrain

• Engine Model: HINO J05E Tier 4 Final (or Isuzu CC-6BG1T in older units)
• Rated Power Output: ~160 hp (119 kW) @ 2,000 rpm
• Maximum Torque: ~650–700 Nm
• Fuel Tank Capacity: ~400 liters
• Travel Speed: 3.5–5.5 km/h
• Swing Speed: ~11 rpm
• Gradeability: Up to 35°

Hydraulic System

• Main Pump Type: Variable displacement axial piston pump
• Flow Rate: ~2 × 220–240 L/min
• System Pressure: Up to 34.3 MPa
• Hydraulic Oil Capacity: ~250 liters
• Boom Cylinder Bore: ~130 mm
• Arm Cylinder Bore: ~115 mm
• Bucket Cylinder Bore: ~105 mm

Performance Metrics

• Bucket Capacity: 0.8–1.2 m³
• Max Digging Depth: ~6.7 meters
• Max Reach (Horizontal): ~10.2 meters
• Max Dump Height: ~6.9 meters
• Bucket Digging Force: ~150–160 kN
• Arm Digging Force: ~110–120 kN

Cab and Operator Features

• Cab Type: ROPS/FOPS certified
• Display: Color LCD monitor with diagnostics and fuel tracking
• Controls: Electro-hydraulic joysticks with customizable sensitivity
• Comfort: Air-conditioned cab, high-back suspension seat, noise-insulated interior
• Visibility: Wide glass area, rear-view camera, LED work lights

Smart Features and Efficiency

• Fuel Efficiency: VG turbocharger + high-pressure common rail injection
• Emissions Control: EGR cooler + DPF system (Tier 4 Final compliant)
• Auto Idle & Eco Mode: Reduces fuel consumption during low-load operations
• Telematics Ready: KOMEXS system for remote diagnostics and fleet tracking

Attachments Compatibility

• Standard Bucket: 0.8–1.2 m³
• Optional Tools: Hydraulic breaker, demolition shear, compactor, ripper
• Quick Coupler: Hydraulic or manual options available

Refurbishment Scope

Refurbished SK210 units typically include:

• Engine overhaul (injectors, turbo, seals, DPF cleaning)
• Hydraulic pump recalibration or replacement
• Electrical system rewiring and sensor testing
• Cab restoration (seat, controls, HVAC, monitor)
• Structural repairs (boom welding, bushing replacement, repainting)

Overview of the Kobelco SK210 Excavator

The Kobelco SK210 is designed to offer a balance between power, efficiency, and comfort. Its hydraulic system delivers smooth performance, while its robust engine provides the strength necessary for tough jobs. The SK210 is equipped with advanced technology and features that enhance both operator performance and fuel savings, making it suitable for a wide range of heavy-duty tasks, including digging, lifting, grading, and demolition.

Refurbished Kobelco SK210 units are often preferred by businesses looking to save on capital expenditure while maintaining the quality and capabilities of new machinery. These excavators are carefully restored and inspected to meet factory specifications, ensuring they deliver exceptional performance and reliability.

Key Features of the Kobelco SK210 Excavator

The Kobelco SK210 is built to handle a variety of construction tasks with ease. Here are the key features that make this excavator stand out:

Engine and Power

• Engine: The Kobelco SK210 is powered by a Hino J05E-TP engine, capable of producing 123 kW (165 horsepower). This engine provides the necessary power for demanding excavation, digging, and material-handling tasks while being fuel-efficient.

• Fuel Efficiency: One of the standout features of the SK210 is its exceptional fuel efficiency. The excavator uses Kobelco’s ECO mode, which optimizes fuel consumption based on the job's needs. This contributes to lower operating costs and reduced emissions, benefiting both the environment and the bottom line.

Hydraulic System

• Advanced Hydraulic Technology: The SK210 is equipped with Kobelco’s advanced hydraulic system, which maximizes productivity by providing faster cycle times and enhanced lifting capabilities. The hydraulic system’s design ensures that power is distributed efficiently, making the machine faster and more responsive.

• Load-Sensing Hydraulics: The load-sensing system adjusts the hydraulic pressure according to the workload, allowing the excavator to perform with optimal efficiency under varying load conditions. This not only improves fuel consumption but also reduces wear on the components.

Operator Comfort and Cabin Design

• Spacious Cabin: The Kobelco SK210 features an ergonomically designed operator cabin that prioritizes comfort and ease of use. The cabin is spacious with a high-back seat, adjustable armrests, and ample legroom, ensuring that the operator remains comfortable during long hours of operation.

• Visibility and Controls: The cabin provides excellent visibility from all angles, ensuring that the operator can clearly see the working area. The joystick controls are intuitive, reducing the physical effort required to operate the machine, thus enhancing productivity.

• Climate Control: Many models of the SK210 come equipped with air conditioning and heating, providing a comfortable working environment regardless of the weather conditions.

Maneuverability and Stability

• Undercarriage Design: The SK210 features a heavy-duty undercarriage with durable tracks, rollers, and sprockets that enhance its stability and maneuverability. It is designed to perform well on uneven or rough terrain, making it ideal for construction sites and other demanding environments.

• Improved Ground Clearance: The SK210 is equipped with a high ground clearance, ensuring that it can handle rough and muddy surfaces while maintaining excellent traction.

Performance and Capacity

• Digging Depth and Reach: The Kobelco SK210 has an impressive digging depth of up to 6.9 meters (22.6 feet) and a maximum digging reach of approximately 9.8 meters (32 feet). This allows it to perform deep excavation tasks with ease.

• Lifting Capacity: The SK210 is capable of lifting up to 3.7 tons of material at a radius of 3 meters (9.8 feet), making it suitable for lifting and moving heavy materials such as steel beams and large rocks.

• Bucket Capacity: The machine is fitted with a bucket capacity ranging from 0.8 to 1.2 cubic meters, depending on the attachment used. This versatility allows the SK210 to handle various materials, from dirt and gravel to rocks and debris.

Advantages of Purchasing a Refurbished Kobelco SK210 Excavator

Investing in a refurbished Kobelco SK210 offers numerous advantages, especially for businesses looking to balance performance and cost-effectiveness. Below are some key benefits of opting for a refurbished model:

Cost Savings

Refurbished Kobelco SK210 excavators come at a significantly lower price than new machines, providing an opportunity to acquire high-quality equipment without a heavy upfront investment. Purchasing a refurbished machine can result in savings of 30-40% compared to buying a new one.

Certified Quality

Refurbished units are typically overhauled by certified professionals, ensuring that every component is inspected, repaired, and replaced as necessary. This includes the engine, hydraulic system, undercarriage, and all key mechanical parts. As a result, the refurbished SK210 provides the same level of performance and reliability as a new machine.

Faster Return on Investment (ROI)

Because of the lower purchase price, a refurbished Kobelco SK210 offers a faster return on investment (ROI) compared to a new unit. With its durability and ability to complete tough tasks efficiently, the refurbished excavator quickly starts earning money for your business.

Environmental Impact

Opting for a refurbished machine helps reduce the environmental impact associated with manufacturing new machines. By purchasing a refurbished Kobelco SK210, you contribute to reducing waste and conserving resources, which is in line with modern sustainability goals.

Maintenance and Care for the Kobelco SK210 Excavator

Proper maintenance is crucial to ensure that your Kobelco SK210 continues to perform at its best over the years. Here are some essential maintenance tips for the SK210:

Engine Maintenance

• Follow the recommended oil change intervals and use high-quality oil to ensure the engine operates efficiently.

• Inspect and replace air filters regularly to maintain optimal engine performance.

• Monitor coolant levels and check for leaks to prevent engine overheating.

Hydraulic System Maintenance

• Regularly check hydraulic fluid levels and ensure that there are no leaks in the hydraulic lines and seals.

• Replace hydraulic filters as part of routine maintenance to prevent blockages and maintain system efficiency.

• Clean and lubricate hydraulic components to reduce wear.

Track and Undercarriage Maintenance

• Inspect the tracks, rollers, and sprockets for wear and tear regularly. Adjust the track tension as needed to avoid excessive wear.

• Clean the undercarriage of dirt, mud, and debris to prevent damage to the components.

• Lubricate the undercarriage to ensure smooth movement and to prolong the lifespan of the tracks.

Cabin and Safety Features

• Regularly inspect and maintain safety equipment, including seat belts, emergency lights, and warning systems.

• Clean the cabin and ensure that visibility is unobstructed. Check that the controls, air conditioning, and other features are functioning correctly.

Conclusion

The Kobelco SK210 is a highly reliable and powerful excavator suitable for a wide range of construction and earthmoving applications. Its combination of advanced hydraulic systems, fuel-efficient engine, and operator-friendly design makes it a top choice for contractors seeking a high-performance machine.

A refurbished SK210 offers significant cost savings, while still delivering the performance and reliability of a new machine. Proper maintenance and care will help ensure that the excavator continues to provide excellent service for years to come. For any business looking to optimize their equipment fleet, the Kobelco SK210 is a solid investment that delivers both short-term savings and long-term value.

Our Commitment

1. 2 years / 4000 hours warranty.
2. EPA certified.
3. No sweatshop labor.
